After microchip pic18f14k22 mcu flash memory fuse bit has been broken, engineer can start to Recover Microprocessor PIC18F14K22 Flash Program from its protected memory after cracking microprocessor pic18f14k22 heximal file;
- Memory Endurance: The Flash cells for both program memory and data EEPROM are rated to last for many thousands of erase/write cycles – up to 10K for program memory and 100K for EEPROM. Data retention without refresh is conservatively estimated to be greater than 40 years.
- Self-programmability: These devices can write to their own program memory spaces under internal software control to readout pic18f14k22 protected mcu program. Using a bootloader routine located in the code protected Boot Block, it is possible to create an application that can update itself in the field.
- Extended Instruction Set: The PIC18F1XK22/LF1XK22 family introduces an optional extension to the PIC18 instruction set, which adds 8 new instructions and an Indexed Addressing mode. This extension has been spe- cifically designed to optimize re-entrant applica- tion code originally developed in high-level languages, such as C.
- Enhanced CCP module: In PWM mode, this module provides 1, 2 or 4 modulated outputs for controlling half-bridge and full-bridge drivers. Other features include:
- Auto-Shutdown, for disabling PWM outputs on interrupt or other select conditions to extract pic18f13k50 flash memory program;
- Auto-Restart, to reactivate outputs once the condition has cleared
- Output steering to selectively enable one or more of 4 outputs to provide the PWM signal.
- Enhanced Addressable USART: This serial communication module is capable of standard
RS-232 operation and provides support for the LIN bus protocol. Other enhancements include automatic baud rate detection and a 16-bit Baud Rate Generator for improved resolution.
- 10-bit A/D Converter: This module incorporates programmable acquisition time, allowing for a channel to be selected and a conversion to be initiated without waiting for a sampling period and thus, reduce code overhead.
Extended Watchdog Timer (WDT): This enhanced version incorporates a 16-bit postscaler, allowing an extended time-out range that is stable across operating voltage and temperature. See Section 25.0 “Electrical Specifications” for time-out periods.
